NV511

Maximum Capacity	510 g
Readability	0.0005 lb (0.1 g)
Pan Size	5.4 in x 7.5 in (138 mm x 190 mm)
Item Number:	83033083

Overview
Specs
Accessories
Documents

Overview

The Navigator NV has a winning combination of modern features, including touchless sensors that provide hands-free operation, a large LCD display, ultra-fast response time, and superior overload protection. With maximum capacities up to 5kg, Navigator NV offers the best-in-class combination of features, versatility and performance that fit a wide range of industrial, food and laboratory weighing applications.

Applications

Weighing, Parts Counting, Percent Weighing, Checkweighing, Totalization, Display Hold

Display

Backlit Liquid Crystal Display (LCD)

Operation

AC adapter (included) or 4 AA batteries (not included)

Communication

RS232, USB or Ethernet with integrated cable (available as accessories)

Construction

ABS housing, stainless steel pan, transportation lock, security bracket, calibration lock switch, two touchless sensors, up-front level indicator

Design Features

User-selectable communication and print settings, mechanical and software overload/underload protection, auto shut-off

Specifications

Maximum Capacity	510 g
Readability	0.0005 lb (0.1 g)
Pan Size	5.4 in x 7.5 in (138 mm x 190 mm)
Battery Life	80 Hours with Disposable Batteries
Communication	Ethernet (Available as an Accessory);RS232 (Available as an Accessory);USB (Available as an Accessory)
Auxiliary Display Model	Not Applicable
Dimensions	8.4 in x 2.3 in x 8 in (212 mm x 58 mm x 204 mm) (LxHxW)
Display	LCD with backlight
In-Use Cover	Available as an Accessory
Legal for Trade	Not Applicable
Linearity ±	0.2 g
Net Weight	3.1 lb (1.4 kg)
Pan Construction	Stainless Steel
Power	4 AA (LR6) Batteries (Not Included);AC Adapter (Included)
Repeatability, typical	0.1 g
Stabilization Time	1 s
Tare Range	To capacity by subtraction
Transportation Case	Available as an Accessory
Units of Measurement	Singapore Tael;Ounce Troy;Pennyweight;Grain;Pound:Ounce (fractional);Tical;Pound: Ounce;Newton;Taiwan Tael;Gram;Hong Kong Tael;Pound;Tola;Carat;Ounce
Working Environment	50°F – 104°F, 85%RH, non-condensing (10°C – 40°C, 85% RH, non-condensing)
