RC60LS/1

Maximum Capacity	132.2 lb (60 kg)
Readability	0.005 lb (2 g)
Platform Size	13.8 in x 9.4 in (350 mm x 240 mm)
Item Number:	80252651

Overview
Specs
Accessories
Documents

Overview

The OHAUS Ranger Count line of compact bench scales offer durable, cast aluminum housings, high-speed processors and large backlit LCD's for fast and accurate measurements. With EC Type Approved models, minimum Average Piece Weights (APW) from 0.01 g to 0.2 g, and software optimized for fast and adaptive counting

Applications

Weighing, Dynamic Weighing, Parts Counting

Display

Backlit LCD with bar-graph capacity guide

Operation

Built-in AC Power Supply or Optional Internal Rechargeable Battery

Communication

RS232 Interface

Construction

Rugged cast aluminum housing with stainless steel platform

Design Features

Enhanced high speed microprocessor technology for fast and accurate reading, auto reference optimization and auto-add mode, recommended minimum APW of: 0.2 x readability

Specifications

Maximum Capacity	132.2 lb (60 kg)
Readability	0.005 lb (2 g)
Platform Size	13.8 in x 9.4 in (350 mm x 240 mm)
Units of Measurement	Gram;Kilogram;Pound;Tonne;Ounce
Working Environment	14°F – 104°F, 80%RH, non-condensing (-10°C – 40°C, 80%RH, non-condensing)
Platform Construction	Stainless Steel
Second Scale Input	Not Applicable
Protection Rating	Not Applicable
In-Use Cover	Available as an Accessory
Transportation Case	Available as an Accessory
Power	Rechargeable Battery (Included);AC Adapter (Included)
Communication	RS232 (Included)
Width (Shipping)	53 cm
Height (Shipping)	30 cm
Length (Shipping)	53 cm
Gross Weight (Shipping)	11.1 kg
