D150VX

Maximum Capacity	300 lb (150 kg)
Readability	0.05 lb (20 g)
Platform Size	25.6 in x 19.7 in (650 mm x 500 mm)
Item Number:	80250543

Overview
Specs
Accessories
Documents

Overview

The Defender™ V Series bases offer economical yet durable performance for industrial weighing in washdown environments. With NTEP certification, Measurement Canada and EC approval, these bases can be used for both general applications as well as where legal for trade performance is required.

Applications

N/A

Display

N/A

Operation

N/A

Communication

N/A

Construction

304 grade stainless steel platform, stainless steel tubular frame, IP67 stainless steel load cell, level indicator

Design Features

125% capacity overload protection

Specifications

Maximum Capacity	300 lb (150 kg)
Readability	0.05 lb (20 g)
Platform Size	25.6 in x 19.7 in (650 mm x 500 mm)
Protection Rating	IP67
Dimensions	25.6 in x 5.6 in x 19.7 in (650 mm x 143 mm x 500 mm) (LxHxW)
Platform Construction	Stainless Steel
Net Weight	73 lb (33 kg)
Legal for Trade	NTEP Certified; EC Type Approvable; Measurement Canada Approved
Readability (Certified)	0.1 lb (50 g)
Working Environment	14°F – 104°F, 85%RH, non-condensing (-10°C – 40°C, 85%RH, non-condensing)
