MB27
The Affordable High Capacity Moisture Analyzer

MB27

Maximum Capacity 90 g
Readability Moisture Content 1 mg/0.01%
Pan Size 3.5 in (90 mm)
Item Number: 30251683
Overview
The new OHAUS MB27 Basic Moisture Analyzer combines high quality and durable construction into a sleek, compact design. The MB27 offers dependable, accurate results for a wide variety of moisture analysis applications.
Applications
Percent Moisture Determination, Percent Solid Determination, Weighing
Display
Backlit liquid crystal display (LCD)
Operation
Power cord (included)
Communication
RS232 (included)
Construction
Halogen heat source, ABS housing, metal pan support, metal pan handler, in-use cover
Design Features
3 shut off criteria (manual, timed or auto), 1 standard heating profile, 50° to 160° C heating range (5° C increments)
Specifications
Maximum Capacity 90 g
Readability Moisture Content 1 mg/0.01%
Pan Size 3.5 in (90 mm)
Heater Type Halogen Lamp
Communication RS232
Dimensions (HxLxW) 5 in x 11 in x 6.5 in (127 mm x 280 mm x 165 mm)
Display LCD, backlight
In-use cover Included
Net Weight 5 lb (2.1 kg)
Power AC Adapter (Included)
Shut-Off Criteria Automatic - Preset Weight Loss/Time;Manual;Timed
Temperature Range 50 °C – 160 °C
Units of Measurement %;Gram
Working Environment 50°F – 104°F, 80%RH, non-condensing (10°C – 40°C, 80%RH, non-condensing)
Accessories

Item Number

80252581

Description

Cable, ST103-AV DV EX MB PA TxxP

Item Number

30064203

Description

Printer, Impact, SF40A, AM

Item Number

80251992

Description

Printer, Thermal, STP-103, US

Item Number

80500571

Description

Cable, SF42-AV DV MB Ranger

Item Number

80500525

Description

Cable, RS232, IBM 9P, AV DV MB Ranger

Item Number

80252475

Description

In-Use-Cover, MB23 MB25

Item Number

80252476

Description

Holder, Pan, MB Series

Item Number

80252477

Description

Cage, Sample, MB Series

Item Number

80252478

Description

Pan, Reusable, Set(3), 7mm, MB Series

Item Number

80252479

Description

Pan, Reusable, Set(3), 14mm, MB Series

Item Number

80850043

Description

Anti-Theft Device, MB AX EX Scout-HD

Item Number

80850086

Description

Pan, Aluminum, Set(80), MB Series

Item Number

80850087

Description

Filter, Glass Fiber, Set(200)

Item Number

11113857

Description

Temp. Calibration Kit, MB Series
